Specification
| Processor |
Intel® Core™ i5-13420H, 8C (4P + 4E) / 12T, P-core 2.1 / 4.6GHz, E-core 1.5 / 3.4GHz, 12MB
|
| Graphics |
Integrated Intel® UHD Graphics
|
| Chipset |
Intel® SoC Platform
|
| Memory |
8GB Soldered DDR4-3200
|
| Memory Slots |
One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable
|
| Max Memory |
Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200
|
| Storage |
512GB SSD M.2 2242 PCIe® 4.0x4 NVMe® Opal 2.0
|
| Storage Support
|
Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB each
|
| Storage Slot |
Two M.2 slots • One M.2 2242 PCIe® 3.0 x4 slot • One M.2 2242 PCIe 4.0 x4 slot
|
| Card Reader |
No card reader
|
| Optical |
None
|
| Audio Chip |
High Definition (HD) Audio, Synaptic® CX11880 codec
|
| Speakers |
Stereo speakers, 2W x2, Dolby Atmos®
|
| Camera |
HD 720p with Privacy Shutter
|
| Microphone |
2x, Array
|
| Battery |
57Wh
|
| Power Adapter |
65W USB-C® (3-pin)
|
| DESIGN | |
| Display
|
14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC
|
| Touchscreen |
None
|
| Keyboard |
Backlit, English
|
| Case Color |
Graphite Black
|
| Case Material |
Aluminium (Top), PC-ABS (Bottom)
|
| Pen |
Pen Not Supported
|
| Dimensions (WxDxH)
|
313 x 219.3 x 17.99 mm (12.32 x 8.63 x 0.71 inches)
|
| Weight
|
Starting at 1.41 kg (3.11 lbs)
|
| SOFTWARE | |
| Operating System |
Windows® 11 Pro, English
|
| Bundled Software |
None
|
| CONNECTIVITY | |
| WLAN + Bluetooth
|
Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.1
|
| WWAN |
Non-WWAN
|
| SIM Card |
None
|
| Ethernet |
100/1000M (RJ-45)
|
| NFC |
None
|
| Standard Ports |
|
| Docking |
Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® E14 Gen 5 (Intel®)
|
| SECURITY & PRIVACY | |
| Smart Card Reader |
None
|
| Security Chip |
Discrete TPM 2.0 Enabled
|
| Fingerprint Reader |
Touch Style, Integrated in Power Button
|
| Physical Locks |
Kensington® Nano Security Slot™, 2.5 x 6 mm
|
| Other Security |
Camera privacy shutter
|
| MANAGEABILITY | |
| System Management |
Non-vPro®
|
| SERVICE | |
| Base Warranty |
1-year, Courier or Carry-in
|
| Included Upgrade |
3Y Onsite upgrade from 1Y Courier/Carry-in
|
